Frit Furnace Crucible Dense Zirconia Corundum
PARAMETRI DEL PRODOTTO
Descrizione
Dense Zirconia-Corundum Crucible for Frit Furnaces
This dense zirconia-corundum crucible for frit furnaces is a specialized refractory vessel manufactured through high-temperature, dense sintering using high-purity alumina, zirconia, and silica as primary raw materials. The product features excellent high-temperature performance, resistenza allo shock termico, and resistance to corrosion by molten glass. It is specifically designed for glass melting operations—such as those in frit furnaces—and is suitable for high-temperature melting processes involving ceramic frits, glass glazes, and similar materials.
Caratteristiche del prodotto
- High Zirconia Content; Strong Corrosion Resistance
With a ZrO₂ content of 41.058% combined with 44.089% Al₂O₃, the material forms a dense zirconia-corundum structure. It offers excellent chemical corrosion resistance against high-temperature melts—such as molten glass and frit—effectively extending the crucible’s service life.
- Dense Structure; Excellent Thermal Shock Resistance
Produced via a high-temperature densification sintering process, the material features a dense structure and low porosity. It exhibits superior thermal shock resistance, enabling it to withstand the frequent temperature fluctuations of frit furnaces without cracking.
- Low Impurity Content; No Contamination of Melt
With Fe₂O₃ and TiO₂ contents of only 0.049% E 0.073% respectively, the material contains minimal harmful impurities. It does not react with frit or glaze at high temperatures, effectively ensuring the purity of the melted material.
- Stable High-Temperature Performance
The zirconia-corundum material maintains structural stability and resists deformation at high temperatures. It withstands erosion by molten glass, making it suitable for the continuous, long-term operation of frit furnaces.
| Test Item | Test Result |
|---|---|
| Al₂O₃ (%) | 44.089 |
| SiO₂ (%) | 12.234 |
| ZrO₂ (%) | 41.058 |
| HfO₂ (%) | 0.844 |
| TiO₂ (%) | 0.073 |
| Fe₂O₃ (%) | 0.049 |
| K₂O (%) | 0.076 |
| Na₂O (%) | 1.177 |
| CaO (%) | 0.038 |
| MgO (%) | 0.017 |
Aree di applicazione
- Ceramic Frit Melting: Used for melting and holding ceramic frit in frit furnaces.
- Glass Glaze Melting: Suitable for high-temperature melting processes involving glass glazes, pigments, and similar materials.
- Specialty Glass Industry: Used as a melting vessel for optical glass and specialty glass.
- Non-ferrous Metal Smelting: Suitable for high-temperature smelting applications requiring superior corrosion resistance.
Profilo Aziendale
Un'impresa professionale specializzata in servizi tecnologici di trattamento termico e il marchio R&D, produzione, e vendita di forni elettrici ad alta temperatura.
L'azienda si concentra sullo sviluppo di forni elettrici ad alta temperatura che coprono un intervallo di temperature compreso tra -100 ℃ e 2600 ℃. I suoi prodotti includono forni elettrici sperimentali, forni in atmosfera sottovuoto, forni industriali, e apparecchiature di riscaldamento a induzione a media frequenza. I prodotti principali includono forni a scatola, forni tubolari, forni di sollevamento, forni a spinta, forni a carrelli, forni rotanti, forni a tunnel, e vari forni specializzati a media frequenza.
L'azienda aderisce all'innovazione tecnologica e ha superato le certificazioni ISO9001 e EU CE. Possiede 21 marchi registrati, 29 brevetti, E 27 diritti d'autore sul software.
Metodi di pagamento
TT
Metodi di spedizione
Il forno elettrico è confezionato in Il forno elettrico è confezionato in tre strati: prima avvolto in carta schiuma, poi avvolto in pellicola di plastica, e infine imballato in una cassa di legno.
Domande frequenti (Domande frequenti)
- What are the main advantages of dense zirconia-corundum crucibles?
The primary advantages are excellent corrosion resistance—derived from high zirconia content—and good thermal shock resistance due to the material’s dense structure. Additionally, the extremely low impurity content ensures no contamination of the melt, making them suitable for the long-term, high-temperature operation of frit furnaces.
- What is the applicable temperature range for these crucibles?
The dense zirconia-corundum material can withstand temperatures exceeding 1600°C. Specific operating temperatures can be determined based on the customer’s process conditions; we recommend consulting a sales engineer.
- Can the products be customized to specific dimensions?
SÌ. Crucibles can be customized in various shapes and sizes based on the customer’s frit furnace model, capacity, and process requirements.
- Will the crucible affect the color or properties of the frit or glaze?
NO. The product has extremely low levels of impurities such as Fe₂O₃ and TiO₂ and exhibits excellent chemical stability at high temperatures. It does not react with the melt, effectively ensuring the purity and color quality of the molten material.
- How can the service life of the crucible be extended?
It is recommended to raise and lower the temperature slowly in accordance with operating procedures to avoid rapid heating or cooling. Do not strike the bottom of the crucible when charging materials; periodically inspect the inner walls for corrosion and replace the crucible in a timely manner.
