1100°C Top-Opening Box-Type Atmosphere Sealing Furnace
PRODUCT PARAMETERS
Description
1100℃ Top-Opening Box-Type Atmosphere Sealed Furnace | XLS High-Temperature Atmosphere Furnace
This 1100℃ top-opening box-type atmosphere sealed furnace (XLS series) features an integrated sealed box structure design, specifically developed and manufactured for protected atmosphere sintering, high-temperature heat treatment, and materials testing. The equipment utilizes high-purity alumina lightweight insulation material and an imported Kanthal resistance wire heating system, combined with hot air circulation stirring technology, to achieve high-precision temperature control and excellent furnace temperature uniformity.
The furnace door employs an electric lifting and pneumatic locking structure, ensuring excellent overall sealing performance and meeting the high-temperature treatment requirements of nitrogen, inert atmospheres, and special process environments. The equipment is widely used in ceramics, electronics, glass, powder metallurgy, new materials, and scientific research fields.
This equipment features intelligent touchscreen control, multi-segment programmable temperature control, PLC atmosphere control, and a comprehensive safety protection system, making it an ideal device for high-temperature atmosphere experiments and industrial heat treatment.
Product Features (Atmosphere Sealed Box Furnace)
- Large-capacity furnace chamber, five-sided heating
This box-type atmosphere-sealed box furnace has a furnace chamber size of 1000×1000×800mm (depth×width×height). The heating elements use imported Kanthal resistance wire, evenly distributed around the furnace chamber and at the bottom, forming a five-sided three-dimensional heating field. There are three temperature control points (one on the left and right, one at the front and back, and one at the bottom), with a furnace temperature uniformity of ±5℃ and a temperature control accuracy of ±1℃.
- Electric lifting furnace door, pneumatic locking
The furnace door uses an electric lifting mechanism and is equipped with a pneumatic locking mechanism. A handle switch controls the opening and closing height. The furnace body is completely sealed, making operation convenient and the seal reliable.
- Hot air stirring system, uniform temperature
The top of the furnace chamber is equipped with 310S stainless steel fan blades, which rotate to stir and regulate the temperature inside the furnace chamber. The stirring motor is water-cooled, and its speed is infinitely variable via a frequency converter, with an additional switch for individual control. Effectively eliminates temperature stratification, ensuring uniform temperature distribution within the furnace.
4.2P Chiller with Water-Cooled Sealing Ring Protection
The furnace opening and top sealing areas are CNC machined and feature a water-cooling structure to dissipate heat from the sealing rings, preventing damage due to overheating. The furnace power interface uses vacuum electrodes to ensure a durable seal.
- Vacuum Sealing Structure
The furnace body seal uses high-temperature fluororubber rings, providing excellent overall sealing performance. The furnace body and door are manufactured through polishing, grinding, pickling, phosphating, powder coating, and high-temperature baking, resulting in a novel and attractive appearance with advantages such as oxidation resistance, acid and alkali resistance, corrosion resistance, high-temperature resistance, and easy cleaning.
- 10-inch Touchscreen Control
Equipped with a 10-inch touchscreen, allowing for temperature curve setting and audible and visual alarms upon program completion. Operation is intuitive, and data recording is complete.
- Multi-Intake System
Eight air inlets are evenly distributed across the left and right sides of the furnace chamber. Two flow meters are integrated into one air inlet, and the air intake switch can be controlled by a PLC program to stop and start. The vent is located at the top (DN30) and is adjustable with a valve.
| Temperature | 1100℃ |
| Specifications (Chamber Dimensions) | 1000×1000×800 mm (D×W×H) |
| Power Supply AC | 380V |
| Power | 65KW |
| Control Range | 80 to 1100℃ |
| Temperature Measuring Element | Type K thermocouple, measuring range 0-1320℃ |
| Temperature Control Points | Three (left/right one, front/back one, bottom one) |
| Heating Element Installation Location | Evenly distributed around the furnace chamber + bottom |
| Heating Element | Imported Kanthal resistance wire |
| Temperature Control Accuracy | ±1℃ (integrated circuit control, no overshoot) |
| Furnace Temperature Uniformity | ±5℃ (depending on chamber size) |
| Hot Air Circulation | Fan blades on top of chamber rotate to stir and evenly distribute temperature inside the chamber |
| Stirring Blade | 310S stainless steel |
| Stirring Motor and Speed | Water-cooled stirring motor, speed infinitely adjustable via VFD (with separate switch control) |
| Chiller | 2P water chiller |
| Heating Rate | Freely adjustable: max 15℃/min, min 1℃/h |
| Furnace Body Structure | High-temperature fluoro rubber seals; furnace mouth and top sealing surfaces CNC machined; water cooling structure on top and mouth for seal cooling; vacuum electrode for power connection; polished, ground, pickled, phosphated, powder coated, high-temperature baked. Aesthetic appearance, oxidation/acid/alkali/corrosion/high temperature resistant, easy to clean |
| Door Opening Method | Electric lift, pneumatic locking, hand switch controls opening/closing height; fully sealed furnace body |
| Refractory Material | Vacuum-formed high-purity alumina lightweight material; furnace mouth and bottom use lightweight hollow ball alumina plate, high service temperature, low heat storage, thermal shock resistance, good insulation (energy saving >80% vs. old furnaces) |
| Insulation Material | Three-layer insulation: aluminum silicate fiberboard, alumina fiberboard, alumina (polycrystalline) fiberboard (energy saving >80% vs. old furnaces) |
| Furnace Shell Temperature | < room temperature +20℃ during long-term continuous operation |
| Protection | Integrated modular control unit, dual-loop control and protection: overshoot, over/under regulation, broken thermocouple, phase loss, overvoltage, overcurrent, overtemperature, current feedback, soft start, etc. |
| Control | Closed-loop thyristor module trigger control, phase-shift triggering. Output continuously adjustable with constant voltage/current/power characteristics, protecting heating elements |
| Display Parameters | Temperature, segment number, segment time, remaining time, output power %, voltage, current, etc. |
| Touch Screen | 10 inch, for temperature curve setting, audible/visual alarm upon program completion |
| Temperature Curve Setting | Intelligent temperature controller supporting PID/APID/MPT adjustment, self-tuning/self-learning, no overshoot/undershoot, 30-segment program control, arbitrary ramp heating/cooling, program modifiable during operation, curve fitting for smooth control |
| Multi-Curve Input | 30-segment program control: 30 segments for 1 curve, 14 segments each for 2 curves, 9 segments each for 3 curves, 5 segments each for 5 curves; multiple curves can be input simultaneously and called arbitrarily |
| Exhaust Port | DN30 at top, with adjustable valve |
| Air Intake | 8 intake ports evenly distributed on left and right sides, two flow meters integrated into one intake port, gas intake switch controllable via PLC program |
| Furnace Bottom Plate | 310S high-temperature backing plate to prevent impact damage to refractory material |
| Included Accessories | One crucible tongs, one pair of high-temperature gloves |
Application Areas (Atmosphere Sealed Box Furnace)
- Advanced Ceramic Sintering: Suitable for large-scale atmosphere sintering of high-performance ceramics such as alumina, zirconium oxide, silicon nitride, and silicon carbide. Five-sided heating + hot air stirring ensures uniform furnace temperature; large-capacity furnace chamber suitable for mass production.
- Metallic Material Heat Treatment: Suitable for annealing, tempering, normalizing, and other heat treatment processes of metallic materials. A protective atmosphere can be introduced to prevent oxidation; a sealed structure ensures atmosphere stability.
- Powder Metallurgy: Suitable for atmosphere sintering of metal powders and alloy powders; the 310S high-temperature pad is wear-resistant and durable.
- New Material R&D: Suitable for the synthesis and heat treatment process research of new materials such as special ceramics, composite materials, and high-temperature alloys.
- Universities and Research Institutes: Suitable for experimental teaching and research projects in materials science, metallurgical engineering, and related fields.
- Industrial and Mining Enterprises: Suitable for mass production, process verification, and quality inspection. Electric lifting furnace door + pneumatic locking improves operational efficiency.
Company Profile
A professional enterprise specializing in heat treatment technology services and the R&D, manufacturing, and sales of high-temperature electric furnaces.
The company focuses on developing high-temperature electric furnaces covering a full temperature range of -100℃ to 2600℃. Its products include experimental electric furnaces, vacuum atmosphere furnaces, industrial kilns, and medium-frequency induction heating equipment. Main products include box furnaces, tube furnaces, lifting furnaces, pusher kilns, bogie furnaces, rotary kilns, tunnel kilns, and various specialized medium-frequency furnaces.
The company adheres to technological innovation and has passed ISO9001 and EU CE certifications. It owns 21 registered trademarks, 29 patents, and 27 software copyrights.
Payment Methods
TT
Shipment Methods
The electric furnace is packaged in three layers: first wrapped in foam paper, then wrapped in plastic film, and finally packed in a wooden crate.
Frequently Asked Questions (FAQ)
- What gas environments is this atmosphere furnace suitable for?
Suitable for nitrogen and various inert protective atmospheres.
- How is the furnace door opened?
It adopts an electric lifting opening and pneumatic locking structure, making operation safe and convenient.
- How is the temperature uniformity inside the furnace?
The equipment uses a hot air circulation stirring system, achieving a furnace temperature uniformity of ±5℃.
- Does it support automatic program operation?
It supports 30-segment automatic program control, enabling automatic heating, heat preservation, and cooling.
- Can multiple temperature curves be input simultaneously?
Multiple program curves can be input and recalled at any time.
