1600°C Atmosphere Vacuum Furnace Water-cooled High-Temperature Furnace

High-Temperature Vacuum Sintering and Atmosphere Protection Equipment

This 1600℃ atmosphere vacuum furnace is specifically designed for high-temperature vacuum sintering and atmosphere-protected heat treatment processes. It integrates a temperature control system, vacuum system, gas path system, pressure protection system, and intelligent program control system, making it suitable for high-end material research and development and industrial-grade heat treatment applications.

The equipment employs an 1800-type U-shaped silicon molybdenum rod heating system, combined with a high-purity alumina fiber insulation structure, achieving stable high-temperature output and excellent furnace temperature uniformity. The entire machine is compatible with vacuum and multiple atmospheres, meeting the diverse and complex process requirements of scientific research experiments and industrial production.

Product Features(Vacuum Furnace)

1. Maximum Operating Temperature 1600℃, No Derating During Long-Term Use

This equipment has a maximum operating temperature of 1600℃ and can operate continuously at 1600℃ without derating limitations. It uses 1800-type U-shaped silicon molybdenum rod heating elements, arranged on both sides of the furnace chamber, ensuring stable output and long lifespan under ultra-high temperature conditions.

2. Water Cooling System, Protecting Critical Components

Equipped with 3-meter-long inlet and outlet water pipes (water source to be provided by the customer). Water cooling includes the furnace opening and top of the furnace chamber. Multi-channel pure aluminum water circulation heat sinks are used to effectively reduce water temperature. A chiller can be arranged separately if needed.

3. Comprehensive Vacuum and Atmosphere System

The vacuum pump is to be provided by the customer. The furnace body is equipped with a digital display vacuum gauge, with a vacuum value reaching -0.1Mpa. The furnace chamber steel plate is 6-20mm thick, double-sided welded, and can withstand a positive pressure of 0.1Mpa. Gas valves are made of stainless steel and equipped with a three-way mass flow meter for precise control of various gas flow rates. It can handle various atmospheres including hydrogen, nitrogen, argon, carbon monoxide, and oxygen.

4.7-inch Touchscreen for Intelligent Operation

Equipped with a 7-inch touchscreen, it displays parameters such as temperature, segment number, segment time, remaining time, output power percentage, voltage, and current. It features 30-segment program control, allowing input of multiple curves and supporting commands such as jump, loop, run, pause, and stop. The program can be modified at any time during operation.

5. Multiple Safety Protections

Pressure Protection: A signal from an electrical contact pressure gauge or pressure sensor drives the control module to close the electromagnetic intake valve, activate the electromagnetic exhaust valve and alarm, releasing pressure from the exhaust port with audible and visual alarms.

Application Areas(Vacuum Furnace)

• Ultra-High Temperature Ceramic Sintering: Suitable for high-temperature vacuum or atmosphere sintering of high-performance ceramics such as zirconium oxide, silicon nitride, silicon carbide, and aluminum nitride, improving density and mechanical properties.
• Hard Alloys and Powder Metallurgy: Suitable for vacuum sintering of tungsten carbide-based hard alloys and metal powder compacts, preventing oxidation and ensuring alloy hardness and strength.
• Semiconductor and Electronic Materials: Suitable for high-temperature heat treatment of semiconductor materials such as silicon, silicon carbide, and gallium nitride, as well as sintering and atmosphere treatment of electronic ceramics, magnetic materials, and packaging materials.
• High-Purity Material Heat Treatment: Suitable for annealing, degassing, and purification processes of high-purity metals and compounds under vacuum or protective atmosphere, ensuring material purity.
• New Material R&D and Scientific Research Experiments: Suitable for process research of new materials such as composite materials, nanomaterials, special alloys, and high-temperature superconducting materials, as well as experimental teaching and research projects in materials science and metallurgical engineering majors in universities and research institutes.

Company Profile

A professional enterprise specializing in heat treatment technology services and the R&D, manufacturing, and sales of high-temperature electric furnaces.

The company focuses on developing high-temperature electric furnaces covering a full temperature range of -100℃ to 2600℃. Its products include experimental electric furnaces, vacuum atmosphere furnaces, industrial kilns, and medium-frequency induction heating equipment. Main products include box furnaces, tube furnaces, lifting furnaces, pusher kilns, bogie furnaces, rotary kilns, tunnel kilns, and various specialized medium-frequency furnaces.

The company adheres to technological innovation and has passed ISO9001 and EU CE certifications. It owns 21 registered trademarks, 29 patents, and 27 software copyrights.

Payment Methods

TT

Shipment Methods

The electric furnace is packaged in three layers: first wrapped in foam paper, then wrapped in plastic film, and finally packed in a wooden crate.

Vacuum Furnace Frequently Asked Questions (FAQ)

1. What is the maximum temperature of this equipment?

The maximum operating temperature is 1600℃, and it supports long-term stable operation.

2. Does it support vacuum sintering?

Yes. The equipment can perform high-temperature sintering and heat treatment experiments in a vacuum environment.

3. What gases can be introduced?

Supports multiple protective atmospheres, including inert gases and reactive gases.

4. Does it have safety protection functions?

It has multiple safety systems, including overpressure, overtemperature, phase loss, current protection, and gas leak alarms.

5. Can it be customized?

Customization of furnace size, vacuum system, gas path, and automation control scheme is supported according to customer needs.
